Part of the Bulletin 800H series, the 800H-DP6 push button is engineered for durability and reliability in demanding industrial settings. Its red mushroom head provides clear visibility and easy operation, making it suitable for emergency stop functions. The device is constructed with high-quality materials to withstand harsh conditions and is designed for panel mounting. It does not include contact blocks, allowing users to customize contact configurations based on specific application requirements. The 800H-DP6 is suitable for use in hazardous locations classified under Class I, Division 1 & 2, Groups B, C, and D, as well as Class II, Division 1 & 2, Groups E, F, and G.
Features:
- Operator Type: Mushroom head, momentary contact
- Head Color: Red
- Illumination: Non-illuminated
- Barrel Type: Standard length
- Contact Blocks: Not included; customizable per application
- Mounting: Panel mount
- Hazardous Location Rating: Type 7 (Class I, Div 1 & 2, Groups B, C, D); Type 9 (Class II, Div 1 & 2, Groups E, F, G)
- Environmental Rating: NEMA Type 4/13
- Operating Temperature: -20°C to +70°C
- Certifications: UL Listed, CSA Certified
